C Struct Padding: Why Your 16-Byte Payload Becomes 32 Bytes
C Struct Padding: Why Your 16-Byte Payload Becomes 32 Bytes
LeetCode graph tricks are useless if you don't understand raw memory in C. I learned this the hard way in my Grind repo.
I ran into a performance bottleneck where a seemingly small 16-byte data structure was causing double the expected L1 cache misses. The culprit was careless struct member ordering, silently doubling its memory footprint to 32 bytes.
In C, compilers align struct members to optimize memory access, often to the size of the largest member or the CPU's word size. This introduces 'padding' bytes to ensure subsequent members start at an address that's a multiple of their size.
Consider struct { char a; int b; char c; }. Logically, this is 1 + 4 + 1 = 6 bytes. However, int b needs 4-byte alignment. If char a is at address 0, int b cannot start at address 1; it will start at address 4, leaving 3 padding bytes. char c then follows int b. The entire struct will often be padded to a multiple of 4, making its size 12 bytes.
This principle scales up. A logical 16-byte payload, due to similar padding, can occupy 32 bytes in memory.
